Custom Designed Cutting Tools Made in New Zealand
Carbide Tools

ALU CUT End Mill 2 Flute Ball Nose Long Series

MICRO GRAIN SOLID CARBIDE

DESIGN FEATURES: Helix angle 30º, Right hand cutting, Centre cutting

Suitable for general purpose milling of most materials, steels, non-ferrous materials
* On request: Out of Range / Other sizes and uncoated product​

Request Pricing

Description

wdt_ID Cutting Diameter Flute Length Overall Length Shank Diameter TiALN Product Code
1 2mm 19 57 6 53U20200051
2 3mm 19 57 6 53U20300057
3 4mm 19 57 6 53U20400057
4 5mm 25 64 6 53U20500064
5 6mm 28 76 6 53U20600076
6 7mm 29 76 8 53U20700076
7 8mm 29 76 8 53U20800076
8 9mm 32 102 10 53U20900102
9 10mm 32 102 10 53U21000102
10 11mm 51 102 12 53U21100102
11 12mm 51 102 12 53U21200102
12 14mm 57 127 14 53U21400127
13 16mm 57 127 16 53U21600127
14 18mm 57 127 18 53U21800127
15 20mm 57 127 20 53U22000127
16 22mm 57 127 22 53U22200127
17 25mm 57 127 25 53U22500127
19
