Custom Designed Cutting Tools Made in New Zealand
MICRO GRAIN SOLID CARBIDE
DESIGN FEATURES: Helix angle 30º, Right hand cutting, Centre cutting
Available in 40º helix for harder material
Suitable for general purpose milling of most materials, steels, non-ferrous materials
* On request: Out of Range / Other sizes and uncoated product
| wdt_ID | Cutting Diameter | Flute Length | Overall Length | Shank Diameter | TiALN | Product Code |
|---|---|---|---|---|---|---|
| 1 | 3mm | 19 | 57 | 6 | • | 61U40300057 |
| 2 | 4mm | 19 | 57 | 6 | • | 61U40400057 |
| 3 | 5mm | 25 | 64 | 6 | • | 61U40500064 |
| 4 | 6mm | 28 | 76 | 6 | • | 61U40600076 |
| 5 | 8mm | 29 | 76 | 8 | • | 61U40800076 |
| 6 | 10mm | 32 | 102 | 10 | • | 61U41000102 |
| 7 | 12mm | 51 | 102 | 12 | • | 61U41200102 |
| 8 | 14mm | 57 | 127 | 14 | • | 61U41400127 |
| 9 | 16mm | 57 | 127 | 16 | • | 61U41600127 |
| 10 | 18mm | 57 | 127 | 18 | • | 61U41800127 |
| 11 | 20mm | 57 | 127 | 20 | • | 61U42000127 |
| 12 | 22mm | 57 | 127 | 22 | • | 61U42200127 |
| 13 | 25mm | 57 | 127 | 25 | • | 61U42500127 |
